Brand
Tomei
Compatibility
EVO 1 – 9
Part Number
252003
SPEC
PISTON
| Bore (Φ) |
Pin Dia (Φ) |
Length (mm) |
Recess | Comp.Height (mm) |
PistonCrownVolume (cc) |
Weight (g) |
Pin weight (g) |
Total weight (g) |
|---|---|---|---|---|---|---|---|---|
| 85.5 | 22.0 | 60 | â—‹ | 31.65 | 20.5 | 327 | 113 | 440 |
| 86.0 | â—‹ | 20.5 | 335 | 448 |
| Top ring B×T(mm) | Second ring B×T(mm) | Oil ring B×T(mm) |
|---|---|---|
| 1.2×3.05 | 1.2×3.7 | 2.5×2.85 |
CRANKSHAFT
| Stroke (mm) | Weight (kg) | STD Stroke (mm) |
|---|---|---|
| 100.0 | 18.5 | 88.0 |
CONNECTING ROD
| Conrod | Conrod Bolt | Conrod Bearing | Material | ||||
|---|---|---|---|---|---|---|---|
| Length (mm) |
L.Diam×Length (mm) |
S.Diam×Length (mm) |
Bolt Size | Height Under Neck (mm) |
Inner Circum (mm) |
Bearing Width (mm) |
|
| 147.0 | φ48×26.4 | φ22×23 | 3/8-24 | 40 | 45 | 21.0 | SNCM439 |
Compression Ration Specs
| Bore | φ85.5 | φ86.0 | |
|---|---|---|---|
| Gasket Thickness (mm) |
1.0 | 9.2 | 9.3 |
| 1.2 | 9.1 | 9.2 | |
| 1.5 | 8.9 | 9.0 | |
| 1.8 | 8.7 | 8.8 | |
| Gasket Bore | 86.5 | ||
