Brand
HKS
Compatibility
Nissan 400Z RZ34
OEM part Number
80300-AN018
| FRONT | REAR | |
|---|---|---|
| Damping force adjustment | 30 steps | 30 steps |
| Base valve | – | – |
| Height adjustable lower bracket | 〇 | 〇 |
| Upper mount | Rubber | Rubber |
| Inverted/Normal type | Normal | Normal |
| Damper/Spring layout | Coilover | Separated |
| Spring rate change at factory | Possible | Impossible |
| Damping force adjustment with wire | – | – |
| Helper spring (Spring rate N/mm) |
〇 (19.8) |
Spring rate
| F | R | |
|---|---|---|
| Spring rate N/mm(kgf/mm) | 118 ( 12.0 ) | 108 ( 11.0 ) |
| Free height (mm) | 200 | – |
| Spring type | Straight | Special shape |
| Recommended range to change spring rate N/mm(kgf/mm) | ±20 ( 2 ) | – |
Specification of damper
| F | R | |
|---|---|---|
| Damping force (Rebound/Damping)N* | 1206 / 608 | 662 / 402 |
| Default position of dial | 15 | 15 |
| Remaining damper stroke (Rebound/Damping)mm | 46 / 41 | 71 / 59 |
