Brand
HKS
Compatibility
Nissan 400Z RZ34
OEM part Number
80310-AN007
| FRONT | REAR | |
|---|---|---|
| Damping force adjustment | 30 steps | 30 steps |
| Base valve | – | – |
| Height adjustable lower bracket | 〇 | 〇 |
| Upper mount | Spherical bearing | Spherical bearing |
| Inverted/Normal type | Normal | Normal |
| Damper/Spring layout | Coilover | Separated |
| Spring rate change at factory | Possible | Possible |
| Damping force adjustment with wire | – | – |
| Helper spring (Spring rate N/mm) |
〇 (19.8) | 〇 (19.8) |
| Factory *2 | Test data | Adjustable range High – Low *3 |
Drivable range High – Low *4 |
||
|---|---|---|---|---|---|
| FRONT | Ride height *1 | 687 | 676 | 715 ～ 658 | 715 ～ 658 |
| Against stock | -27 | -38 | 1 ～ -56 | 1 ～ -56 | |
| REAR | Ride height *1 | 691 | 676 | 717 ～ 661 | 717 ～ 661 |
| Against stock | -26 | -41 | 0 ～ -56 | 0 ～ -56 |
